NewerTech USB 2.0 Universal Drive Adapter

Review - NewerTech USB 2.0 Universal Drive Adapter

by , 9:00 AM EST, February 20th, 2007

Keeping spare empty drive cases around so you can access bare hard drives is kind of a pain: You have to install the drive before you can use it, and you need different cases for each drive connection type. If you are looking for a way to quickly access hard drives that doesn't require cases, NewerTech's USB 2.0 Universal Drive Adapter is just what you need.

The Universal Drive Adapter bypasses the need for extra hard drive cases by including an ATAPI/IDE connector for 3.5-inch hard drives and optical drives, an SATA connector, and an ATAPI connector for 2.5-inch laptop hard drives all on a single USB cable. It doesn't require any special drivers, and practically doesn't even need a manual.


Everything you need to connect to laptop and desktop drives is included.

3.5-inch and SATA drives require an external power source, so the adapter includes a power supply and plugs for each drive type. Since laptop hard drives are bus powered, they just plug in and work.

I did find, however, that the bare laptop drive I used for some of my tests couldn't get enough power from the built-in USB ports on a PowerBook G4 or an iBook G4. Connecting the adapter to a powered USB hub provided enough juice for the drive to spin up and mount on my Desktop, so if you plan on adding the Universal Drive Adapter to your tech support field kit, consider including a powered USB hub as well - for just in case.


A laptop drive connected to the adpater.

Drives connected to your Mac via the adapter work as they should, and perform at normal USB 2.0 speeds. That means you should plan a little extra time if you are using the adapter to transfer large amounts of data to another drive.

The three plugs on the adapter head hold to drives securely, which is nice since it is intended for short-term use only. This is one place that NewerTech could have cut corners and justified sloppy work by noting the adapter is for temporary use. Instead, the plugs are all well designed and stay attached to drives just as they should.


An IDE drive with adapter and power supply.

If you plan on using the Universal Drive Adapter at your workbench or desk, it's fairly easy to keep the parts together. But if this is going into your field gear - a scenario I expect is fairly common with consultants and traveling tech support teams - a carrying pouch is necessary to avoid losing parts. Unfortunately, that's not included with the kit. NewerTech's carrying pouch is a US$4.95 add-on, and unless you already have a pouch big enough for all the parts, it's probably a good idea to buy one along with the adapter kit.

The Bottom Line
NewerTech's USB 2.0 Universal Drive Adapter is an essential tool for any consultant, tech support team, or anyone else that needs to use hard drives that aren't mounted in cases. It's easy to use, works cross platform, and supports the three most common drive connections, making this a versatile all-in-one adapter.

Digg!


Product: USB 2.0 Universal Drive Adapter

Company: Newer Technology

List Price: $24.95

4 out of 5 stars

Pros: Supports desktop and laptop drives, no software necessary, easy to use.
Cons: May draw more power than some built-in USB ports can supply, no carrying case.

Observer Comments

Show: Subjects Only | Full Comments
Close Name:Guest
Subject: Handy, but poor quality

We bought one of these months ago and it has been a handy diagnostic and troubleshooting device. However, it is very cheaply made. A consistent and troubling issue is that the power connector to the AC adaptor has a very bad fit. We have had to use other power cords and always have to fiddle with it to get it just right so it's under power.

Close Name:gopher Posts: 291 Joined: 28 Mar 2002
Subject: The one thing I miss, Firewire

If it had Firewire it would be an instant sell for me. With Firewire I can boot both PowerPC and Intel Macs without issues. With USB, I'm stuck with Mac OS 9 or Intel Mac booting.

Close Name:Guest
Subject: Do not buy this!!!

I was very excited about this when it first came out last year. I bought one immediately. The power supply did not work. The green light never went on. I didn't think much of it and got a replacement for the whole kit. The first thing I did was plug in the power supply. The light came on, so no problem. After unplugging, I attached a drive and plugged back in. The light on the power supply did not come on and the drive did not spin up. I removed the drive. The power supply light did not come back up. I put the drive back into one of my regular drive cases and the drive did not spin up! The drive was completely dead. Thankfully, I did a little Googling and tried replacing the drive control board with a board from an identical drive. Wouldn't you know it, but it fixed the drive. However, now I had another drive with no control board. I ended up going to eBay and spending $40 on a replacement. I didn't even bother trying to get another replacement from Newertech, not that I would ever connect another drive to one of their products ever again.

So despite what this review says, I would say: don't buy this unless you are willing to face the possibility of a dead hard drive. There is something wrong with the power supplies included with this. You definitely get what you pay for.

Steve

Close Name:strells Posts: 4 Joined: 21 Feb 2007
Subject: Read my comment just above...

I am the Guest who wrote "Do not buy this!!!" I accidentally posted without logging in. If you are even considering this product, please read my comments.

Steve

Close Name:Guest
Subject:

I bought this thing and I like it a lot. The instruction sheet that came with it said to set my drive's jumpers to "Master." When I did one of my two formatted partitions disappeared. I put the jumper back to the default "Cable Select" position and it works great. The drive is a new Seagate 320G PATA. I got it to back up my eMac's hard drive. Sure I can't boot with this adapter, but for doing backups it's been great. It connects to any PATA or SATA HD. Cool! What do you want for $25? If you want a similar firewire solution, get the WiebeTech ComboDock for $170.

Close Name:Guest
Subject: Hey, strells

If you read this, send a note to potter at surfacingNOSPAM dot com. Your comment was deleted, but I wanted to know if you had the same problem I do now.

I just got one of these UDA kits and hooked it up to a BRAND NEW Seagate 120 GM PATA drive. Backed up 115 GB of data to the drive and everything seemed fine.


Now, three days later and the drive is completely DEAD. Won't get power or spin up. Thanks, OWC!

Close Name:Guest
Subject: Strells

Bah, the posts were just hidden.

Yup, looks like the same exact problem. Crap.

Close Name:Guest
Subject: on my second one, and guess what?

it, too, is dead. The power supply does not work. It may have ruined one of my drives (i haven't tested the drive yet in a normal enclosure)...

VERY CHEAPLY MADE PRODUCT!!!

I bought one and it didn't work. I had to ship it back to NewerTech. They sent me a replacement which doesn't work. I just emailed them this morning. I haven't heard from them about what to do...

I think I would just like a refund. Hopefully they are cool like that.

Close Name:Guest
Subject: Now they did

OS 10.4.3 and later will boot via USB 1.1 and 2.0, on almost all Macs starting with the slot-loading iMac and the Powerbook G3 Firewire (in other words, NOT the B&W G3, the PCI G4, the clamshell iBook, and the Powerbook G3 Wallstreet and Lombard). A USB drive won't always appear in Startup Disk, but it will appear in Startup Manager (what you get when you hold down the Option key at powerup, before the Mac's screen lights up, and keep it held down until you get a screen showing all attached bootable volumes).
